Seeed Studio Sipeed Tang Primer FPGA Development Board

Seeed Studio Sipeed Tang Primer FPGA Development Board

Amazon.com Price: $19.90 (as of 24/05/2020 12:24 PST- Details)

Target application scenario:
High-speed communication interface interconnection
Learning, debugging, research of soft cores such as RISC-V

Description

Specifications:
△Center unit: Anlogic Applied sciences EG4S20
△Logical unit: 20K (LUT4/LUT5 hybrid structure)
△SRAM: Approximately 130KB
△SDRAM: Integrated 32bit bit width 64MBit
△Flash: FPGA configuration Flash, 8Mbit Person Flash, nor/nand optional
△Obtain and debug: Onboard FPGA JTAG Obtain Debugger, RV debugger can debug hummingbird core
△Interface:
-FPC40P socket, may also be hooked up to RGB LCD, VGA adapter board
-FPC24P socket, may also be hooked up to DVP digicam, Prime velocity ADC module
-Resistive contact display controller for I2C interface, used with RGB LCD
△Pin and lead:
-The adjoining pins LVDS are drawn in the similar period, prime out 8 GCLKs, and all 8 ADCs are taken out.
-Double row pin spacing 900mil, appropriate with breadboard development
-Part hollow ends up in an additional 40 IO, and the entire board ends up in one hundred thirty+ IO
△Electric features:
-Micro USB 5V energy provide; 2.54mm pin
-three.3V~5V energy provide; 1.27mm stamp hollow energy supply
-three-channel DCDC energy provide chip, solid and environment friendly energy supply
-unbiased adjustment of Bank0 IO level

Specifications:
△Combine, Obtain, debug options with TD IDE
△IDE has a wealthy IP core
△Enhance hummingbird risc-v comfortable Center :https://github.com/Lichee-Pi/Tang_E203_Mini
Goal utility state of affairs:
Prime-velocity conversation interface interconnection
Finding out, debugging, analysis of sentimental cores equivalent to RISC-V
Device imaginative and prescient processing
Parallel computing acceleration
